When it comes to speed and flexibility, there is nothing on the market to compare with our SynView, a powerful, modular multiviewer that can handle both UHD and any IP video format. Featuring vastly improved specifications, SynView is the industry’s only single field latency (20ms@50Hz and 16,7ms@59.94Hz) multiviewer system to offer external. IP Multiviewers 3067VIP10G-3G-HW Advanced Multi-Image Display Processors with 10GbE Interface 3067VIP10G-J2K-HW JPEG2000 Advanced Compact Multi-Image Display Processor.
Cinegy offers the opportunity for most of its products to try them before making a purchase decision.
Below you can find some of our products which you can evaluate free of charge.
Please click on the product name to register for the evaluation download link which will be emailed to you.
If you wish to evaluate each product, you will need to register for each product individually.
Cinegy’s real-time playout server, multi-channel broadcast automation and branding software for scheduled, studio, news and live operations |
Cinegy's professional monitoring and analysis solution for SDI and IP streams |
Cinegy’s live vision mixer for SDI and IP streams |
Cinegy’s professional broadcast video player |
| The Player for Daniel2 video files and all other professional video formats |
Network appliance software for real-time ingest |
| Cinegy’s server-based transcoding and batch processing service |
Output through a generated RTP/UDP stream
that can be viewed in any part of the world
Multi-layout views
of sources with an integrated, intuitive layout designer
Stream info display:
stream encoding, format, resolution, fps
Dynamic GUI widgets:
digital and analog clock, CPU meter, etc.
View streaming output
from Cinegy Air or Cinegy Capture servers
‹›The Most Flexible Multiviewer Ever
Streams from satellites, camera feeds, playout devices and other local or remote sources all need to be monitored. Cinegy Multiviewer displays these signals before analyzing them and raising alerts for any detected signal problems. Running as a service operating on commodity IT equipment, video streams can be received over IP/NDI via Ethernet or using standard SDI or SMPTE-2110 cards.
Monitoring 6x HD channels and creating live MPEG-DASH H.264 stream output (1 Mbit/s)Cinegy Multiviewer enables broadcasters and production houses to monitor streams from satellites, camera feeds, playout devices and other sources locally and remotely. Featuring a robust analysis and alert system, detecting signal problems as they occur, Cinegy Multiviewer runs on commodity IT servers or workstations receiving NewTek NDI or regular RTP/UDP streams via Ethernet or uncompressed video using standard SDI or SMPTE-2110 cards from vendors such as AJA, BMD or Deltacast. Decoding support for DANIEL2, MPEG-2, H.264 and HEVC up to 8K in full 4:2:2 colour, along with MPEG audio, AAC and AC-3 decoding is built in.
Fully customizable
Cinegy Multiviewer can easily adapt to your requirements with a fully customizable interface that can be designed using a WYSIWYG multi-layout editor. Cinegy Multiviewer can multiple 4K or even 8K monitors depending on the GPU used, providing enough real-estate and video resolution for even the most demanding control room. For those times when the control room is not near the equipment, or the viewer is not in the control room, Cinegy Multiviewer supports streaming of the output screen in up to 8K 4:2:2 resolutions, making any of the configured multiple layouts viewable anywhere in the building or in the world with remote control via a web interface.
Saving costs
Cinegy Multiviewer can receive single program or multiplexed feeds (MPTS) from standard satellite or cable receivers, relaying entire transponders via RTP/UDP onto the network, dramatically reducing the number of IRDs required for monitoring return feeds. Cinegy Multiviewer also supports local SDI inputs for low-latency SDI and SMPTE-2110 signal monitoring as well as NewTek NDI streams.
Full SRT Support
Cinegy Multiviewer includes SRT support to receive streams reliably and secure via unreliable networks (e.g. Internet) which is another step to reduce costs and facilitate remote and cloud production.
Versatile monitoring
Cinegy Multiviewer displays channel name, audio level indicators, as well as real-time video previews, playing the incoming video at full frame rate. In addition, the alarm indicators display signal presence of audio and video, VANC components (CC, AFD, V-Chip), while VU meters dynamically show all present audio channels (stereo, 5.1, etc.) and LKFS loudness with DialNorm. If any signal component is outside defined parameters, a corresponding alarm indicator lights up, log entries are generated, and a predefined alert is sent via email, SNMP, HTTP or API. If your stream contains Closed Captions, DVB subtitles or OP-42/OP-47 teletext, Cinegy Multiviewer can decode and display these in-place over the related video.
Free Ip Multiviewer Software Free
Scalability
Cinegy Multiviewer is ideal for local and remote operations. It can be massively scaled from just a few to hundreds of channels while remaining fully supported in a cloud-based or hosted service environment.
Cinegy Multiviewer is very easy to manage due to its fully customizable interface where each channel input representation is equipped with a set of preview components and indicators. It allows an operator to monitor as many channels as needed, indicating the real-time status of each channel and a view of the resulting video from any station in the network, in any part of the world.
The Multiviewer output also supports fully-customizable designs with multi-layout views of sources with an integrated, intuitive layout designer – all of which when deployed can be rendered directly to a standard screen or even recompressed and streamed back to the network.
- Supports SD, HD, UHD or 8K sources
- Multiple SDI or SMPTE-2110 inputs, NewTek NDI inputs or MPEG-TS IP streams
- SRT support for receiving IP signals and sending output streams
- DVB subtitles decoding
- Multilayer output
- EIA 608/708 closed captions decoding
- Integrated MPEG audio as well as AAC, AC-3 decoding
- LKFS loudness monitoring and alarming
- Alarms via e-mail, SMS or HTTP
- VANC, AFD and V-Chip indicators
- Local output to multiple HD, UHD or 8K screens
- Screen layout streaming to MPEG-TS, NewTek NDI or SRT
- Remote control via HTTP
- Fully customizable layouts with layout designer
Supported MPEG-TS sources
- Video: MPEG-2, H.264, H.265, DANIEL2 - 4:2:0 and 4:2:2 color space
- Audio: MPEG-audio, AAC-HE2 and AC-3
Supported SDI boards
- AJA Kona and Corvid series
- Blackmagic Design DeckLink and Intensity series
- Deltacast SDI cards
Free Ip Multiviewer Software
Supported SMPTE-2110 boards
- AJA Kona IP
- Deltacast DELTA-ip series
Supported NDI sources
- NewTek NDI v3.0 and up
Cinegy's professional monitoring and analysis solution for SDI and IP streams
Learn how to work with Cinegy Multiviewer using the following links to a product documentation:
Free Ip Multiviewer Software Download
Read about new features in 'What's new in Cinegy Multiviewer 15' blog post.
Multiviewer Download
Watch video tutorials on Cinegy Multiviewer:
